2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16

2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16
2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16
2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16
2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16
2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16
2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16
2Pcs CD4516BE 4516 IC CMOS Binary Up/Down Counter, D- Type Flip Flop, 11 MHz, 3 V to 18 V, DIP-16

Product Specification:

  • The CD4516BE is a CMOS presettable binary Up/Down Counter consists of four synchronously clocked D-type flip-flops connected as counters. This counter can be cleared by a high level on the RESET line and can be pre-set to any binary number present on the jam inputs by a high level on the PRESET ENABLE line. If the CARRY-IN input is held low, the counter advances up or down on each positive-going clock transition.
  • Synchronous cascading is accomplished by connecting all clock inputs in parallel and connecting the CARRY-OUT of a less significant stage to the CARRY-IN of a more significant stage. The CD4516B can be cascaded in the ripple mode by connecting the CARRY-OUT to the clock of the next stage.
  • If the UP/DOWN input changes during a terminal count, the CARRY-OUT must be gated with the clock and the UP/DOWN input must change while the clock is high. This method provides a clean clock signal to the subsequent counting stage.
  • Logic Family / Base Number: CD4516; Counter Type: Binary, Up / Down; Clock Frequency: 11 MHz; Count Maximum: 15: No. of Pins: 16 Pins; Supply Voltage: 3V - 18V; Logic IC Base Number: 4516.
  • Package Include: 2 x 4516 IC


Write a review

Please login or register to review
0 samples sold
7517 views
₹150.00
